Cylinder with High Precision Linear Guide Search Results

16 results found. ( 1~10 to Showing )

JKX-SD12-Stroke
JKXS-SD12-Stroke

Series	JKX
Type	Ball Spline
Cylinder Bore[mm]	12mm	Operating Type	Double Acting
Extrusion Force	57.0N	Stroke	10～100mm
Guide	Ball Spline	Loading Work Piece Mass	-
Product Mass[g]	106g～
Minimum Operating Speed	50mm/s	Maximum Operating Speed	700mm/s
Maximum Operating Cycle	-cpm	Operating Temperatura Range[°]	5〜60゜
Minimum Operating Pressure[MPa]	0.1MPa	Maximum Operating Pressure[MPa]	0.7MPa
Stroke Adjustment	None	Switch	Available
Additional Function
Provided CAD data	JKX(S)-SD12-ストローク JKX(S)-SD12-ストローク-ZT JKX(S)-SD12-ストローク-FN JKX(S)-SD12-ストローク-WT JKX(S)-SD12-ストローク-WS

JKX

Example Movie of Use

JKX-SD12-Stroke-ZES
JKXS-SD12-Stroke-ZES

Series	JKX
Type	Ball Spline
Cylinder Bore[mm]	12mm	Operating Type	Double Acting
Extrusion Force	57.0N	Stroke	10～100mm
Guide	Ball Spline	Loading Work Piece Mass	-
Product Mass[g]	128.5g～
Minimum Operating Speed	50mm/s	Maximum Operating Speed	700mm/s
Maximum Operating Cycle	-cpm	Operating Temperatura Range[°]	5〜60゜
Minimum Operating Pressure[MPa]	0.1MPa	Maximum Operating Pressure[MPa]	0.7MPa
Stroke Adjustment	Extrusion Adjustment	Switch	Available
Additional Function
Provided CAD data	JKX(S)-SD12-ストロークｰZES JKX(S)-SD12-ストローク-ZTZES JKX(S)-SD12-ストローク-FNZES JKX(S)-SD12-ストローク-WTZES JKX(S)-SD12-ストローク-WSZES

JKX

Example Movie of Use

JKX-SD16-Stroke
JKXS-SD16-Stroke

Series	JKX
Type	Ball Spline
Cylinder Bore[mm]	16mm	Operating Type	Double Acting
Extrusion Force	100.0N	Stroke	10～100mm
Guide	Ball Spline	Loading Work Piece Mass	-
Product Mass[g]	144.5g～
Minimum Operating Speed	50mm/s	Maximum Operating Speed	700mm/s
Maximum Operating Cycle	-cpm	Operating Temperatura Range[°]	5〜60゜
Minimum Operating Pressure[MPa]	0.1MPa	Maximum Operating Pressure[MPa]	0.7MPa
Stroke Adjustment	None	Switch	Available
Additional Function
Provided CAD data	JKX(S)-SD16-ストローク JKX(S)-SD16-ストローク-ZT JKX(S)-SD16-ストローク-FN JKX(S)-SD16-ストローク-WT JKX(S)-SD16-ストローク-WS

JKX

Example Movie of Use

JKX-SD16-Stroke-ZES
JKXS-SD16-Stroke-ZES

Series	JKX
Type	Ball Spline
Cylinder Bore[mm]	16mm	Operating Type	Double Acting
Extrusion Force	100.0N	Stroke	10～100mm
Guide	Ball Spline	Loading Work Piece Mass	-
Product Mass[g]	163.5g～
Minimum Operating Speed	50mm/s	Maximum Operating Speed	700mm/s
Maximum Operating Cycle	-cpm	Operating Temperatura Range[°]	5〜60゜
Minimum Operating Pressure[MPa]	0.1MPa	Maximum Operating Pressure[MPa]	0.7MPa
Stroke Adjustment	Extrusion Adjustment	Switch	Available
Additional Function
Provided CAD data	JKX(S)-SD16-ストロークｰZES JKX(S)-SD16-ストローク-ZTZES JKX(S)-SD16-ストローク-FNZES JKX(S)-SD16-ストローク-WTZES JKX(S)-SD16-ストローク-WSZES

JKX

Example Movie of Use

JKX-SD20-Stroke
JKXS-SD20-Stroke

Series	JKX
Type	Ball Spline
Cylinder Bore[mm]	20mm	Operating Type	Double Acting
Extrusion Force	160.0N	Stroke	1～550mm
Guide	Ball Spline	Loading Work Piece Mass	-
Product Mass[g]	297.5g～
Minimum Operating Speed	50mm/s	Maximum Operating Speed	700mm/s
Maximum Operating Cycle	-cpm	Operating Temperatura Range[°]	5〜60゜
Minimum Operating Pressure[MPa]	0.07MPa	Maximum Operating Pressure[MPa]	1MPa
Stroke Adjustment	None	Switch	Available
Additional Function
Provided CAD data	JKX(S)-SD20-ストローク JKX(S)-SD20-ストローク-ZT JKX(S)-SD20-ストローク-FN JKX(S)-SD20-ストローク-WT JKX(S)-SD20-ストローク-WS

JKX

Example Movie of Use

JKX-SD20-Stroke-ZES
JKXS-SD20-Stroke-ZES

Series	JKX
Type	Ball Spline
Cylinder Bore[mm]	20mm	Operating Type	Double Acting
Extrusion Force	160.0N	Stroke	1～550mm
Guide	Ball Spline	Loading Work Piece Mass	-
Product Mass[g]	460g～
Minimum Operating Speed	50mm/s	Maximum Operating Speed	700mm/s
Maximum Operating Cycle	-cpm	Operating Temperatura Range[°]	5〜60゜
Minimum Operating Pressure[MPa]	0.07MPa	Maximum Operating Pressure[MPa]	1MPa
Stroke Adjustment	Extrusion Adjustment	Switch	Available
Additional Function
Provided CAD data	JKX(S)-SD20-ストロークｰZES/ZEL JKX(S)-SD20-ストローク-ZTZES/ZEL JKX(S)-SD20-ストローク-FNZES/ZEL JKX(S)-SD20-ストローク-WTZES/ZEL JKX(S)-SD20-ストローク-WSZES/ZEL

JKX

Example Movie of Use

JKX-SD20-Stroke-ZFS
JKXS-SD20-Stroke-ZFS

Series	JKX
Type	Ball Spline
Cylinder Bore[mm]	20mm	Operating Type	Double Acting
Extrusion Force	160.0N	Stroke	1～550mm
Guide	Ball Spline	Loading Work Piece Mass	-
Product Mass[g]	342.5g～
Minimum Operating Speed	50mm/s	Maximum Operating Speed	700mm/s
Maximum Operating Cycle	-cpm	Operating Temperatura Range[°]	5〜60゜
Minimum Operating Pressure[MPa]	0.07MPa	Maximum Operating Pressure[MPa]	1MPa
Stroke Adjustment	Retraction Adjustment	Switch	Available
Additional Function
Provided CAD data	JKX(S)-SD20-ストロークｰZFS/ZFL JKX(S)-SD20-ストローク-ZTZFS/ZFL JKX(S)-SD20-ストローク-FNZFS/ZFL JKX(S)-SD20-ストローク-WTZFS/ZFL JKX(S)-SD20-ストローク-WSZFS/ZFL

JKX

Example Movie of Use

JKX-SD25-Stroke
JKXS-SD25-Stroke

Series	JKX
Type	Ball Spline
Cylinder Bore[mm]	25mm	Operating Type	Double Acting
Extrusion Force	250.0N	Stroke	1～650mm
Guide	Ball Spline	Loading Work Piece Mass	-
Product Mass[g]	437.5g～
Minimum Operating Speed	50mm/s	Maximum Operating Speed	700mm/s
Maximum Operating Cycle	-cpm	Operating Temperatura Range[°]	5〜60゜
Minimum Operating Pressure[MPa]	0.07MPa	Maximum Operating Pressure[MPa]	1MPa
Stroke Adjustment	None	Switch	Available
Additional Function
Provided CAD data	JKX(S)-SD25-ストローク JKX(S)-SD25-ストローク-ZT JKX(S)-SD25-ストローク-FN JKX(S)-SD25-ストローク-WT JKX(S)-SD25-ストローク-WS

JKX

Example Movie of Use

JKX-SD25-Stroke-ZES
JKXS-SD25-Stroke-ZES

Series	JKX
Type	Ball Spline
Cylinder Bore[mm]	25mm	Operating Type	Double Acting
Extrusion Force	250.0N	Stroke	1～650mm
Guide	Ball Spline	Loading Work Piece Mass	-
Product Mass[g]	630g～
Minimum Operating Speed	50mm/s	Maximum Operating Speed	700mm/s
Maximum Operating Cycle	-cpm	Operating Temperatura Range[°]	5〜60゜
Minimum Operating Pressure[MPa]	0.07MPa	Maximum Operating Pressure[MPa]	1MPa
Stroke Adjustment	Extrusion Adjustment	Switch	Available
Additional Function
Provided CAD data	JKX(S)-SD25-ストロークｰZES/ZEL JKX(S)-SD25-ストローク-ZTZES/ZEL JKX(S)-SD25-ストローク-FNZES/ZEL JKX(S)-SD25-ストローク-WTZES/ZEL JKX(S)-SD25-ストローク-WSZES/ZEL

JKX

Example Movie of Use

JKX-SD25-Stroke-ZFS
JKXS-SD25-Stroke-ZFS

Series	JKX
Type	Ball Spline
Cylinder Bore[mm]	25mm	Operating Type	Double Acting
Extrusion Force	250.0N	Stroke	1～650mm
Guide	Ball Spline	Loading Work Piece Mass	-
Product Mass[g]	487.5g～
Minimum Operating Speed	50mm/s	Maximum Operating Speed	700mm/s
Maximum Operating Cycle	-cpm	Operating Temperatura Range[°]	5〜60゜
Minimum Operating Pressure[MPa]	0.07MPa	Maximum Operating Pressure[MPa]	1MPa
Stroke Adjustment	Retraction Adjustment	Switch	Available
Additional Function
Provided CAD data	JKX(S)-SD25-ストロークｰZFS/ZFL JKX(S)-SD25-ストローク-ZTZFS/ZFL JKX(S)-SD25-ストローク-FNZFS/ZFL JKX(S)-SD25-ストローク-WTZFS/ZFL JKX(S)-SD25-ストローク-WSZFS/ZFL

JKX

Example Movie of Use

12 »
