Gripper Search Results

• 265 results found. ( 11~20 to Showing )

• HP04R-32C

  Series	HP04R
  Open/Close Type	Parallel Gripper
  Cylinder Bore[mm]	32mm	Number of Lever	2
  Operating Type	Double Acting	Gripping Force(Closing Force) *Only one lever	158.0N
  Stroke	22.0mm	Product Mass[g]	664g～
  Operating Temperatura Range[°]	0°
  Switch	Availabl	Dust Proof Cover	None
  Additional Function	-
  Provided CAD data	HP04R-32C



  Catalog PDF

  DXF

  PARASOLID

  STEP

  Example Movie of Use

• HP04R-40C

  Series	HP04R
  Open/Close Type	Parallel Gripper
  Cylinder Bore[mm]	40mm	Number of Lever	2
  Operating Type	Double Acting	Gripping Force(Closing Force) *Only one lever	258.0N
  Stroke	30.0mm	Product Mass[g]	1390g～
  Operating Temperatura Range[°]	0°
  Switch	Availabl	Dust Proof Cover	None
  Additional Function	-
  Provided CAD data	HP04R-40C



  Catalog PDF

  DXF

  PARASOLID

  STEP

  Example Movie of Use

• HP04R-50C

  Series	HP04R
  Open/Close Type	Parallel Gripper
  Cylinder Bore[mm]	50mm	Number of Lever	2
  Operating Type	Double Acting	Gripping Force(Closing Force) *Only one lever	418.0N
  Stroke	36.0mm	Product Mass[g]	1850g～
  Operating Temperatura Range[°]	0°
  Switch	Availabl	Dust Proof Cover	None
  Additional Function	-
  Provided CAD data	HP04R-50C



  Catalog PDF

  DXF

  PARASOLID

  STEP

  Example Movie of Use

• HP04L-8C

  Series	HP04L
  Open/Close Type	Parallel Gripper
  Cylinder Bore[mm]	8mm	Number of Lever	2
  Operating Type	Double Acting	Gripping Force(Closing Force) *Only one lever	5.8N
  Stroke	8.0mm	Product Mass[g]	27g～
  Operating Temperatura Range[°]	0°
  Switch	Availabl	Dust Proof Cover	None
  Additional Function	-
  Provided CAD data	HP04L-8C



  Catalog PDF

  DXF

  PARASOLID

  STEP

• HP04L-10C

  Series	HP04L
  Open/Close Type	Parallel Gripper
  Cylinder Bore[mm]	10mm	Number of Lever	2
  Operating Type	Double Acting	Gripping Force(Closing Force) *Only one lever	10.0N
  Stroke	12.0mm	Product Mass[g]	90g～
  Operating Temperatura Range[°]	0°
  Switch	Availabl	Dust Proof Cover	None
  Additional Function	-
  Provided CAD data	HP04L-10C



  Catalog PDF

  DXF

  PARASOLID

  STEP

• HP04L-16C

  Series	HP04L
  Open/Close Type	Parallel Gripper
  Cylinder Bore[mm]	16mm	Number of Lever	2
  Operating Type	Double Acting	Gripping Force(Closing Force) *Only one lever	26.0N
  Stroke	16.0mm	Product Mass[g]	168g～
  Operating Temperatura Range[°]	0°
  Switch	Availabl	Dust Proof Cover	None
  Additional Function	-
  Provided CAD data	HP04L-16C



  Catalog PDF

  DXF

  PARASOLID

  STEP

• HP04L-20C

  Series	HP04L
  Open/Close Type	Parallel Gripper
  Cylinder Bore[mm]	20mm	Number of Lever	2
  Operating Type	Double Acting	Gripping Force(Closing Force) *Only one lever	45.0N
  Stroke	22.0mm	Product Mass[g]	368g～
  Operating Temperatura Range[°]	0°
  Switch	Availabl	Dust Proof Cover	None
  Additional Function	-
  Provided CAD data	HP04L-20C



  Catalog PDF

  DXF

  PARASOLID

  STEP

• HP04FR-8A

  Series	HP04FR
  Open/Close Type	Parallel Gripper
  Cylinder Bore[mm]	8mm	Number of Lever	2
  Operating Type	Single Acting Normally Open	Gripping Force(Closing Force) *Only one lever	4.5N
  Stroke	4.0mm	Product Mass[g]	28g～
  Operating Temperatura Range[°]	0°
  Switch	Availabl	Dust Proof Cover	Availabl
  Additional Function	-
  Provided CAD data	HP04FR-8A HP04FR-8A-J



  Catalog PDF

  DXF

  PARASOLID

  STEP

• HP04FR-8C

  Series	HP04FR
  Open/Close Type	Parallel Gripper
  Cylinder Bore[mm]	8mm	Number of Lever	2
  Operating Type	Double Acting	Gripping Force(Closing Force) *Only one lever	6.5N
  Stroke	4.0mm	Product Mass[g]	27g～
  Operating Temperatura Range[°]	0°
  Switch	Availabl	Dust Proof Cover	Availabl
  Additional Function	-
  Provided CAD data	HP04FR-8C HP04FR-8C-J



  Catalog PDF

  DXF

  PARASOLID

  STEP

• HP04FR-10A

  Series	HP04FR
  Open/Close Type	Parallel Gripper
  Cylinder Bore[mm]	10mm	Number of Lever	2
  Operating Type	Single Acting Normally Open	Gripping Force(Closing Force) *Only one lever	7.2N
  Stroke	6.5mm	Product Mass[g]	91g～
  Operating Temperatura Range[°]	0°
  Switch	Availabl	Dust Proof Cover	Availabl
  Additional Function	-
  Provided CAD data	HP04FR-10A HP04FR-10A-J



  Catalog PDF

  DXF

  PARASOLID

  STEP
